We successfully cope with tasks of varying complexity, provide long-term guarantees and regularly master new technologies.
| Technical Compliance | HOME HYDRAULIC LIFT MODEL BTI H-001 |
|---|---|
| Drive System | GEAR-LESS WITH WIREROOP |
| Rated Speed | 0.12 m/s Up to 0.20 m/s |
| Rated Load | Up-to 300 KG |
| Travel Height | Up-to 6000 MM |
| Number of Doors | MAX 4 NO. |
| Pit | 70 MM ( NO PIT IS REQIURED IN CASE THERSHOLD RAMP) |
| Shaft Top Height | 2200 MM IN EXT. SHAFT |
| Platform Control | AUTOMATIC PUSH BUTTON |
| Environment | INDOOR-OUTDOOR |
| Emergency Lowering | BATTERY OPERTAED |
| Control Voltage | 24V |
Downlaod CATALOG BTI LIFT
